51.2V100Ah Home Energy Caricchy Battery

Caratteristica:
1. Marchi di celle di primo livello, Cella A+
2. Cella LFP, più di 6000 Ciclo di vita
3. Modulare e flessibile, support up to 15 batteries connect together to expand the system energy.
4. Circuito di precarica integrato per evitare correnti di sbalzo durante il collegamento con diversi inverter/caricabatterie.
5. Automatic dynamic addressing function when connected multiple batteries together.
6. Rapid shut down function for North American market.
7. Supports 1C discharge rate
8. Support a maximum of 96% DOD under off-grid and back-up application
9. Compatibile con gli inverter più diffusi come Victron, Dire, Buono, Sermatec, Growatt, Potenza voltronica, Megarevo, ROE, Soli ecc

Ottieni una citazione

Categorie: Batteria domestica, Stoccaggio energetico domestico Tag: Batteria domestica, Batteria per l'accumulo di energia domestica, Batteria LifePO4 Batteria

Modello	51.2V100Ah Rack design
Tensione nominale	51.2 V
Rated Capacity	100Ah
Absorption Voltage	56.8 A 58.4 V
Float Voltage	56.0 A 56.8 V
Equalize Voltage (if applicable)	56.8 A 58.4 V (same as absorption)
Absorption Time	60 A 120 minutes
Dimensione(mm)	498x 472 x 182.2 mm
Peso(Kg)	46 Kg
Temperature Compensation	NO
Charge Cut-off Voltage	58.4 V
Discharge Cut-off Voltage	40 V
Recommended Charge Current	50UN
Recommended Discharge Current	50UN
Maximum Continuous Charge Current	100UN
Maximum Continuous Discharge Current	100UN
Peak Discharge Curren	120UN
Bluetooth connection	Yes
Self Heating	NO
IP Standard	IP30
Comunicazione	CAN/RS485/RS232
Switch	Yes
BMS Protection	Charging Overcurrent
	Short circuit
	High/Low temperature
Internal Resistance	≤30mΩ
BMS Leakage Current	≤3mA
Operating Temperature Charge	32°F (0°C) to 131°F (55°C)
Operating Temperature Discharge	-4°F (-20°C) to 131°F (55°C)
Storage Temperature 1 week	-4(-20°C) to 149°F (65°C)
Storage Temperature 1 month	-4°F (-20°C) to 113°F(40°C)
Storage Temperature 1 year	-4°F (-20°C) to 77°F (25°C)
Humidity Operating:	5% A 90 % RH
Humidity Storage:	35% A 85% RH
Certifications	UN 38.3; Ce
Ciclo di vita	6000 cycles
Product Lifespan	10-year (Prorated)
Maximum Parallel	15 units
